Click to open expanded view
Telecommunications Industry
Local area network FTTH, FTTX deployments
Optical Fiber Signal Transmission
Fiber Optic Sensing CATV
Small Size and Ligth Weight
Two FRP as strength member to provide good tensile performance
Gel Filled or gel free , good waterproof performanceASU 80m 100m 120m span customized
|
No.
|
1
|
2
|
3
|
4
|
5
|
6
|
|
Color
|
Blue
|
Orange
|
Green
|
Brown
|
Gray
|
White
|
|
No.
|
7
|
8
|
9
|
10
|
11
|
12
|
|
Color
|
Red
|
Black
|
Yellow
|
Violet
|
Pink
|
Aqua
|
|
Fiber count
|
1-12
|
|
|
Span（m）
|
80
|
120
|
|
Strength Member Material
|
FRP
|
|
|
Strength Member Diameter
|
2.0mm
|
2.5mm
|
|
Strength Member Number
|
2
|
2
|
|
Loose Tube Material
|
PBT
|
|
|
Loose Tube Diameter（mm）
|
2.1mm
|
2.5
|
|
Filling compound in loose tube
|
Thixotropic jelly
|
|
|
Water blocking Material
|
Water blocking yarn
|
|
|
Outer Sheath Material
|
Black HDPE
|
|
|
Outer Sheath Thickness（mm）
|
1.0
|
1.0
|
|
Outer Diameter（mm）
|
6.8
|
8.0
|
|
Cable Weight（kg/km）
|
Approx.44
|
Approx.62
|
|
Short term tensile（N）
|
850
|
1250
|
