No.
|
1
|
2
|
3
|
4
|
5
|
6
|
|
Color
|
Blue
|
Orange
|
Green
|
Brown
|
Gray
|
White
|
|
No.
|
7
|
8
|
9
|
10
|
11
|
12
|
|
Color
|
Red
|
Black
|
Yellow
|
Violet
|
Pink
|
Aqua
|
| Item | Unit | Specification（G.652D） | |
| Mode field diameter | 1310nm | μm | 9.2 ± 0.4 |
| 1550nm | μm | 10.4 ± 0.8 | |
| Cladding diameter | μm | 125.0 ± 1 | |
| Cladding non-circularity | % | ≤1.0 | |
| Core/cladding concentricity error | μm | ≤0.5 | |
| Coating diameter | μm | 242 ± 7 | |
| Coating/cladding concentricity error | μm | ≤12 | |
| Cable cut-off wavelength | nm | ≤1260 | |
| Attenuation Coefficient | 1310nm | dB/km | ≤0.36 |
| 1550nm | dB/km | ≤0.22 | |
| Proof stress level | kpsi | ≥100 | |
| Fiber count | Outer Diameter (mm) |
Weight (g/M) |
Max. Tension(N) Long/Short term |
Max Crush Resistance(N) Long/Short term |
Bending Radius(mm)
Static/Dynamic
|
| 4 | 4.8±0.2mm | 19 | 80/160 | 300/1000 | 10D/20D |
| 6 | 5.0±0.2mm | 23 | 110/330 |
300/1000
|
10D/20D
|
| 8 | 6.0±0.2mm | 26 | 200/600 |
300/1000
|
10D/20D
|
| 12 | 6.8±0.2mm | 35 | 220/660 |
300/1000
|
10D/20D
|
| 24 | 8.0±0.2mm | 60 | 220/660 |
300/1000
|
10D/20D
|
