Optical Fiber Terminal Box Functional Requirements

What are the functional requirements of the fiber optic terminal box? How to choose the price and model of the fiber optic terminal box? The installation requirements of the fiber optic terminal box. For friends who work in fiber optic wiring, the fiber optic terminal box is one of the indispensable products. Let’s take a look at the analysis of the fiber optic cable terminal box series products.

The optical cable terminal box is mainly used for the fixing of the optical cable terminal, the welding of the optical cable and the pigtail, and the storage and protection of the remaining fiber. OTB, optical cable terminal box is mainly used for the fixing of optical cable terminals, the fusion of optical cables and pigtails, and the storage and protection of remaining fibers. Many engineering companies are also called optical cable reel box, which is a box for the protection of optical cable and pigtail fusion at the terminal of optical cable laying. The role of the protective joint.

Installation requirements for fiber optic terminal boxes

1. The installation position, installation method and height of information module, multi-user optical cable terminal box and assembly point distribution module shall meet the design requirements.

2. When installed in the raised floor or on the ground, it should be fixed in the junction box. The information panel can be upright or horizontal. The junction box cover can be opened and should have the functions of waterproof, dustproof and compression resistance. It should be level with the ground.

3. When the bottom box of the optical cable terminal box is equipped with information modules and power sockets at the same time, the spacing and protective measures should meet the design requirements.

4. The fixing method of the base of the optical cable terminal box should be determined according to the specific conditions of the site construction. It can be installed by expansion screws, nails, etc. The fixing method of the information module surface mounted bottom box is determined according to the conditions of the construction site.

5. The fixing screws should be tightened and should not be loose. The installation of the base, the information module and the panel should be firm and stable without looseness, and the panel should be kept on a horizontal plane so as to be beautiful and tidy.

6. The position of the optical cable terminal box installed on the wall should be about 300 mm above the ground. When a raised floor is used on the floor of the room. The cable termination box shall be 300 mm from the access floor surface.

7. There should be signs on various socket panels? Use colors, graphics, and text to indicate the business type of the connected terminal equipment.

8. There should be sufficient space for the optical fiber connectors and the adapter installation bottom box of the optical cable terminated in the work area? And should meet the design requirements

Optical Fiber Terminal Box Functional Requirements

1. It has the function of leading in the optical cable, leading out the distribution pigtail and fixing and protecting the optical cable, distribution pigtail and the performance of the optical fiber in it from damage.

2. It has the function of protecting the optical cable terminal from environmental influences.

3. It has the function of insulating the metal components of the optical cable from the shell of the optical cable terminal box and can be easily grounded.

4. Provide the placement of the optical cable terminal and the remaining space for optical fiber storage, and make the installation and operation convenient.

5. The box body can be fixed with sufficient impact resistance, and has corresponding installation functions for different usage occasions.

6.When necessary, it should have the function of optical cable divergence and connection, and functional requirements.
